I will design pcb, esp32 circuit, layout gerber bom in altium, easyeda kicad

As a professional Electronics and Electrical Design Engineer with over 5 years of hands-on experience, I provide high-quality PCB design services tailored to your exact project requirements. I specialize in embedded systems, circuit schematics, PCB layout design, RF circuits, and product prototyping, delivering reliable and manufacturing-ready solutions for both simple and complex electronic systems.

Whether you have a fully developed concept or just an idea, I can help transform it into a complete, functional, and optimized PCB design. I focus on accuracy, performance, and industry standards to ensure your design is ready for fabrication and real-world use.

My services include complete end-to-end PCB development such as circuit schematic design, professional PCB layout and routing, Gerber file generation, Bill of Materials (BOM), Pick and Place files, assembly drawings, and 3D visual models for better product presentation and validation.

Software expertise includes EasyEDA, Autodesk EAGLE, Fusion 360, and KiCad, allowing me to work efficiently across different design environments and project needs.

I can design:

• 2–6 layer PCBs
• THT and SMT component layouts
• Rigid and flexible PCB structures
• Custom board shapes, sizes, and configurations
• Impedance-controlled routing for RF and high-speed designs

Every project is treated with care, precision, and attention to detail, ensuring optimal performance and manufacturability. Since each design is unique, I offer flexible solutions and custom quotes based on your requirements.

Let’s work together to bring your electronics idea to life with professional, reliable, and production-ready PCB design solutions that meet industry standards and exceed expectations.
